Rheem® Indoor Replacement Coils are designed for use with Rheem outdoor units and are available for vertical upflow or downflow, and horizontal left or horizontal right airflow. When matched with Rheem outdoor units, this coil provides a nominal capacity of 24,000 BTU/HR.
Rheem / Ruud OEM Coil , # RCH2417STAVUA
Features
-
FREE REGIONAL SHIPPING within State of Florida*
-
Constructed of aluminum fins bonded to internally grooved aluminum tubing.
-
Coils are tested at the factory with an extensive refrigerant leak check.
-
Coils have copper sweat refrigerant connections.
-
Feature two sets of 3/4" [14.1 mm] N.P.T. Condensate drain connections for ease of connection.
-
Chatleff metering device connections.
-
Approved for system application with variety of Rheem outdoor units.
-
Condensate drain pan is constructed of high grade, heat resistant, corrosion free thermal-set material.
-
Compatible with Germicidal Light System (UV resistant)
-
Bi-Directional airflow eliminates the need to switch any internal components from horizontal left to right.
-
Unique drain pan design maximizes application flexibility and condensate removal.
-
N-Coil design maximizes performance and minimizes height required at installation.
-
Cabinet width 17"
Replaces / Supersedes: RCH2417 RCH-2417 RCH2417STAVUA RCH-2417STAVUA
Commonly found in: RCSLHU2417CU RCSL-HU2417CU & Various Rheem & Ruud Systems and others
NOTE: In order to remain competitive , we are unable to provide 'FREE Shipping' outside of the State of Florida.
Please Contact Us if you have any concerns or to confirm availability prior to ordering.
Additional products available , Contact Us with your System's Model & Serial Number for more information
