Flood Prevention Switches are simple to install, easy to service and extremely reliable. As water level in the auxiliary or main drain pipe rises due to a clogged air conditioning condensate drain, the switch shuts off the system—thus preventing water from overflowing and causing damage to doors, walls and ceilings. At the heart of the switch is a durable yet precise magnetic reed switch. Constructed of materials that will not rust or stick, the switch operates smoothly every time.
Safe Switch / Condensate Switch # FPSC5002U / CS-2 / FPS-L
Features / Product Specifications
-
FREE SHIPPING!
-
Condensate overflow switch
-
Connect to either red or yellow wire
-
Using the ¾” adapter the FPS-L can be installed on the auxiliary outlet of the primary drain pan
-
Easy access to the switch and the primary drain line for service
Package Includes
-
Pre-wired 6-Foot
-
18 Gauge Lead Wires
-
3/4-inch Threaded Male x Slip Male Adaptor
-
3/4-inch Female Threaded Pan Outlets.
Replaces / Supersedes: SWT3673 SWT-3673 SWT03673 SWT3233 SWT-3233 SWT03233 MARS 21794 685744217947 FPSL FPSC5002U CS-2 CS2 SS2 SS-2 84-SS2 97637 TP-SS2 97634 TP-SS-2 B17153 B17-153 021449976374 10021449976371 662766249958 118955 Safe-T-Switch® Overflow Shut-Off Switch and Similar Float Switches
Our Standex Float Switches are UL® Listed to comply with UL 508 and most applicable building codes. Tested for 6000 cycles at 1.25 amps and listed for use in a 24-volt circuits by Underwriters Laboratories®.
Additional Products & Discounts available...visit our New Website: www.AirstarSolutions.com or Contact Us
Click on any of the links below to download associated documentation.
»
Float Switch Flyer.pdf
»
Submittal Data Sheet FPS-L.pdf
